neqsim-process-safety

NeqSim Process Safety Skill

Systematic hazard identification, layer-of-protection analysis (LOPA), and safety-integrity-level (SIL) determination — the quantitative half of process safety that complements depressurization (neqsim-dynamic-simulation) and relief sizing (neqsim-relief-flare-network).

When to Use

• HAZOP / HAZID node walkdown with deviation guidewords
• Barrier management for PSFs/SCEs with document evidence and performance standards
• LOPA for a specific scenario — calculate residual frequency and required RRF
• SIL determination for an SIF — IEC 61508 / IEC 61511 verification
• Closed-loop SIF execution from live process signal through MooN voting and final element
• Bow-tie analysis (top event with threats + barriers + consequences)
• ALARP / risk-matrix scoring (5×5)
• Trapped-liquid fire rupture screening for blocked-in liquid-filled segments, including PFP demand and source-term handoff
• Overpressure-protection study for a protected item — enumerate credible relief contingencies, select the governing case, size the PSV, and check TR3001 / API 521 compliance
• Fixed-roof tank normal/emergency vent-demand and rated-capacity screening using externally verified API 2000 demand and device evidence

Standards: IEC 61508, IEC 61511, CCPS LOPA Guidelines, API 521 / ISO 23251, API 520, API 2000, TR3001, ASME VIII Div 1 (UG-125), ASME B31.3/B31.4, ASME B16.5, API 754, NORSOK Z-013.

For API 2000, route to Api2000TankVentingScreeningKernel. Require caller-controlled licensed demand factors/cases, externally rated capacities, consistent gas reference conditions, tank pressure/vacuum limits, and evidence attestations. Do not relabel FireProtectionDesign, generic PSV sizing, or an adequate screen as API tank-vent sizing or conformity.

Method 0b — Trapped-Liquid Fire Rupture Screening

Load neqsim-trapped-liquid-fire-rupture when a safety study concerns a blocked-in liquid-filled pipe segment exposed to fire, no pressure relief, PFP endurance, flange/pipe rupture, or a Word/HTML study report based on P&IDs/STID, line lists, material certificates, and fire documents.

Recommended sequence:

1. Retrieve the evidence package with neqsim-stid-retriever: P&ID/STID, line list, piping spec, material certificate, flange/bolt/gasket data, fire-zone/PFP documents, relief basis, and design basis.
2. Extract a structured segment list with neqsim-technical-document-reading: isolation boundary, line numbers, fluid, P/T, ID, wall thickness, length, material grade, flange class, fire basis, PFP endurance, relief availability, acceptance criteria, and evidence gaps.
3. Use TrappedInventoryCalculator to calculate trapped mass and volume.
4. Use FireExposureScenario, MaterialStrengthCurve, and TrappedLiquidFireRuptureStudy to calculate event times and limiting mode.
5. Convert outputs to SafetySystemDemand for PFP checks and to SourceTermResult for consequence handoff if rupture is predicted.
6. Report all screening defaults as assumptions. Missing project data must stay visible in an evidence/gaps register.

Method 0 — Evidence-Linked Barrier Register

Use BarrierRegister, SafetyCriticalElement, SafetyBarrier, PerformanceStandard, and DocumentEvidence when agents read technical documentation and need a traceable handoff into LOPA, SIL, bow-tie, or QRA.

Recommended sequence:

1. Extract DocumentEvidence from P&IDs, C&E charts, SRS, SIL verification reports, inspection reports, vendor datasheets, and operating procedures.
2. Build PerformanceStandard objects for each PSF/SIF/SCE function with target PFD, availability, proof-test interval, response time, and acceptance criteria.
3. Build SafetyBarrier objects with type, status, PFD/effectiveness, equipment tags, hazard ids, owner, evidence, and performance-standard links.
4. Group barriers under SafetyCriticalElement records using process equipment tags.
5. Run MCP runBarrierRegister to get validation findings plus lopaHandoff, silHandoff, bowTieHandoff, and qraHandoff blocks.

Credit rule: do not claim LOPA credit unless the barrier is AVAILABLE, has a valid PFD, has a linked performance standard, and has traceable evidence. Missing evidence must remain visible as a validation finding.

Method 1 — HAZOP Guidewords

Apply the 7 standard guidewords to each design intent at every node:

Output as a HAZOP worksheet table; each row → candidate LOPA scenario.

For automated studies from STID/P&ID documents and NeqSim process simulations, use MCP runHAZOP. It accepts a standard runProcess JSON model plus optional document-extracted nodes, safeguards, evidence references, selected failure modes, and a barrierRegister. The runner executes generated safety scenarios on copied ProcessSystem models and returns IEC 61882 rows, simulation evidence, quality gates, barrier-register handoff, and report markdown. See docs/safety/automated_hazop_from_stid.md.

For a P&ID Safety Analyser / AI-HAZOP front-end that quantifies one deviation at a time, use MCP runHazopScenario (backed by neqsim.mcp.runners.HazopScenarioRunner). It accepts a runProcess JSON model plus an optional guideWord / parameter / nodeTag filter and a limits policy, and returns a stable schemaVersion "1.0" response where every finding carries a computedValue, designLimit, verdict (PASS / EXCEEDS / NOT_EVALUATED), standardReference, and a limitBasis provenance string (HazopConsequenceFinding#getLimitBasis()) so a reviewer can see whether the limit is a data-sheet value or a screening default. Equipment design limits (neqsim.process.mechanicaldesign.DesignConditions) round-trip into DEXPI as a GenericAttributes Set="DesignConditions" group, and blocked-outlet MORE PRESSURE deviations can be screened with neqsim.process.safety.depressurization.BlockedOutletOverpressureAnalyzer. See docs/safety/ai_hazop_input_format.md for the full input-data format.

Method 1b — Quantify the governing deviations of a separator node

A guide-word grid on its own is not decision-grade. For a separation node, four deviations carry the risk; each maps to a class that turns the qualitative row into a number against a data-sheet limit:

Three heuristics that repeatedly decide the outcome:

• Fire is rarely the governing relief case for a high-throughput separator. The fire case only vents vapour generated from the wetted area, while a blocked gas outlet must vent the whole inlet gas rate. Always size both and state which governs — a 10× difference in required orifice area is normal.
• Blow-by on LESS LEVEL is choked in nearly every HP→LP pair, so the rate is set purely by the open area of the level-control valve, not by downstream pressure. When the valve Cv is unknown, present a 2″–8″ equivalent-diameter sensitivity rather than picking one number.
• A thick-walled vessel does not reach MDMT during blowdown. Model the wall (setWall(mass, area, cp, htc)); several hundred tonnes of steel keeps the metal near ambient. The cold spot is the BDV/PSV tail pipe — check it with an isenthalpic PHflash of the gas down to flare pressure, not with the vessel temperature.

Carryover margin scales as 1/(1-level), so report the utilisation as a level sensitivity — it converts "verify the HH trip" into a numeric trip setpoint.

Method 2 — LOPA Worksheet

Use LOPAResult to compute residual frequency:

import neqsim.process.safety.risk.sis.LOPAResult;

LOPAResult lopa = new LOPAResult();
lopa.setScenarioName("V-100 overpressure during compressor surge");
lopa.setInitiatingEventFrequency(0.1);   // /yr — surge event
lopa.setTargetFrequency(1.0e-5);         // /yr — tolerable for safety SIF

// Independent Protection Layers (each must be IEC 61511 IPL-eligible)
lopa.addLayer("BPCS pressure control",     0.10, 0.1,    0.01);
lopa.addLayer("Operator response (alarm)", 0.10, 0.01,   0.001);
lopa.addLayer("PSV @ design",              0.01, 0.001,  1.0e-5);

System.out.println(lopa.toVisualization());
System.out.println("Target met? " + lopa.isTargetMet());
System.out.println("Required additional SIL: " + lopa.getRequiredAdditionalSIL());

IPL eligibility rules (IEC 61511):

• Independent of initiating event and other IPLs
• Specific (one task, one mode)
• Auditable (testable, with proof-test interval)
• BPCS counts as one IPL only (typically PFD = 0.1)

Method 2b — Traceable HAZOP/LOPA to draft SRS

Use LopaScenarioDefinition, ProtectionLayerDefinition, and HazopLopaSrsWorkflow when an approved HAZOP row and user-supplied risk basis need a machine-readable handoff into SRS drafting. The workflow credits a layer only when independence from the initiating event and other layers, specificity, auditability, proof-test/inspection interval, and a controlled evidence reference are all declared. Ineligible safeguards remain visible but receive no frequency reduction.

If a risk gap remains, the result creates a SafetyRequirementSpecificationDraft carrying the HAZOP node/deviation, LOPA reference, SIF tag, trip, safe state, response time, voting, proof-test, reset, and bypass requirements. The draft is always REVIEW_REQUIRED and never fit for construction. No draft is created when credited existing layers meet the supplied target.

After accountable HAZOP, LOPA, and SRS approval, hand the approved inputs to SafetyFunctionDesign, reliability/degraded-mode assessment, and closed-loop transient verification. See docs/process/safety/hazop-lopa-srs-handoff.md.

Method 3 — SIL Determination

After LOPA tells you a SIL is needed, verify with SafetyInstrumentedFunction:

import neqsim.process.safety.risk.sis.SafetyInstrumentedFunction;
import neqsim.process.safety.risk.sis.SafetyInstrumentedFunction.SIFCategory;

SafetyInstrumentedFunction sif = SafetyInstrumentedFunction.builder()
    .id("SIF-001")
    .name("HIPPS on V-100")
    .description("Close XV-1001A/B on PT-1001 high-high (2oo3)")
    .sil(2)                           // claimed
    .pfd(5.0e-3)                      // PFD_avg from supplier verification
    .testIntervalHours(8760.0)        // 1-year proof test
    .mttr(8.0)
    .architecture("2oo3")
    .category(SIFCategory.HIPPS)
    .initiatingEvent("Compressor surge → backflow")
    .safeState("XV closed, V-100 isolated")
    .build();

double rrf = sif.getRiskReductionFactor();    // 1/PFD
int silAchieved = sif.getSil();

SIL bands (IEC 61508):

Method 3b — NOG 070 SIL Catalogue (Norwegian shelf typical SIFs)

For Norwegian-shelf projects, the NOG 070 (070 Norsk olje og gass) guideline gives pre-determined minimum SIL for typical SIFs — use Nog070SilCatalogue / Nog070SilDetermination to look up the minimum and verify the achieved SIL from PFD:

import neqsim.process.safety.risk.sis.nog070.Nog070SifType;
import neqsim.process.safety.risk.sis.nog070.Nog070SilDetermination;

// HIPPS minimum is SIL 3; PFD 1e-4 achieves SIL 3 → compliant
Nog070SilDetermination r =
    Nog070SilDetermination.evaluate(Nog070SifType.HIPPS_PIPELINE, 1.0e-4);
int achieved = r.getAchievedSil();   // 3
int minimum  = r.getMinimumSil();    // 3
boolean ok   = r.isCompliant();      // true
String json  = r.toJson();

Nog070SifType includes HIPPS_PIPELINE, ESD_SUBSEA_ISOLATION (SIL 3), BLOWDOWN_HYDROCARBON_SEGMENT, PSD_PROCESS_SEGMENT (SIL 2), and CUSTOM (supply an explicit minimum via the 3-arg evaluate). Verified by Nog070SilCatalogueTest.

Method 3c — ESD Response-Time Budget (NOG 070 / IEC 61511)

Verify the full detection → logic → final-element chain fits the allowable ESD response time with EsdResponseTimeSimulator:

import neqsim.process.safety.esd.EsdResponseTimeSimulator;
import neqsim.process.safety.esd.EsdResponseTimeSimulator.EsdResponseTimeResult;

EsdResponseTimeResult res = new EsdResponseTimeSimulator()
    .setSifTag("ESD-1234")
    .addDetection("PT-1001 high-pressure", 1.0)         // [s]
    .addLogic("Logic solver scan + 2oo3 vote", 0.5)     // [s]
    .addValve("ESDV-2001", 0.5, 8.0)                    // command delay + stroke [s]
    .setAllowableResponseTimeS(15.0)
    .evaluate();

double total = res.getTotalResponseTimeS();   // 10.0
double margin = res.getMarginS();             // 5.0
boolean within = res.isWithinBudget();        // true

Verified by EsdResponseTimeSimulatorTest.

Method 3d — Closed-loop SIF transient verification

Use ClosedLoopSafetyFunction inside a DynamicSafetyScenario when a response-time budget must be demonstrated against the process model rather than summed from prepared durations. Bind every SafetyFunctionChannel to the isolated process copy, select the SRS voting pattern, then pass an existing ESDLogic, HIPPSLogic, or other ProcessLogic as the final-element sequence.

Recommended sequence:

1. Configure and solve the normal process case.
2. Apply one controlled initiating event on the scenario copy.
3. Bind sensor channels to live process properties, including response delay and an explicit FaultMode for degraded cases.
4. Use the SRS MooN VotingPattern and logic-solver delay.
5. Define dynamic criteria for the actual safe state and deadline, such as ESD valve opening, protected pressure, compressor state, or depressuring pressure.
6. Review DynamicSafetyScenarioResult.getLogicEvidence() for readings, bypass/fault state, vote time, final-element actuation, and trace; do not approve from the boolean verdict alone.

See docs/process/safety/closed-loop-sif-verification.md. This simulation evidence does not infer SIL or approve the SRS; hand the result to the SIL/LOPA and engineering-approval workflow.

Method 3e — Reliability uncertainty and degraded/maintenance modes

After the deterministic SafetyFunctionDesign screen, use SafetyFunctionReliabilityStudy to propagate evidence-based failure-rate, diagnostic-coverage, proof-test, repair-time, beta, and bypass uncertainty. Always provide a fixed seed and retain P10/P50/P90 PFDavg/PFH, target-met probability, iteration count, distributions, and their data sources in the verification package.

Use SafetyFunctionOperatingMode plus SafetyFunctionDegradedModeAssessment before evaluating a bypass or maintenance state. Record every unavailable, forced-trip, or under-repair channel, actual proof-test age, authorization reference, compensating measure, elapsed duration, and maximum duration. The effective architecture (for example 2oo3 to 2oo2) is a demand-capability screen, not permission to preserve the SIL claim or continue operation.

Handoff the assessed mode back to the closed-loop scenario workflow to verify the physical safe state. See docs/process/safety/sif-reliability-and-degraded-modes.md.

Method 3f — Integrated facility safety response

Use FacilitySafetyResponseStudy after the individual engines have executed when one review package must join closed-loop ESD/HIPPS evidence, compressor anti-surge trip demand and observed response, PSV/concurrency results, transient blowdown/flare results, and controlled process limits such as MDMT or hydrate margin. Supply the actual DynamicSafetyScenarioResult and CoupledReliefBlowdownFlareResult; the facility study embeds their maps and must not duplicate their physics.

Capture compressor response with CompressorTripResponse.capture(...). AntiSurge.shouldTrip() is the demand signal; separately record whether the trip was observed, its response time, allowable deadline, and evidence reference. Add each minimum or maximum with ProcessSafetyConstraint and a controlled source reference.

Treat isTechnicallyAcceptable(), isEvidenceComplete(), and isReadyForEngineeringReview() as review gates, never approval. Inspect getFindings() and embedded engine results, then obtain the accountable process-safety, rotating-equipment, flare, piping, and mechanical approvals. See docs/process/safety/integrated-facility-safety-response.md.

Method 3g — Safety change impact and revalidation

Use SafetyStudyRevalidationPlanner with the canonical EngineeringGraph and a controlled ModelChangeEvent. Tag safety lifecycle nodes with the safetyStudyType property and an accepted type: HAZOP, LOPA, SRS, SIF_RELIABILITY, SIF_DYNAMIC_VERIFICATION, RELIEF_BLOWDOWN_FLARE, or FACILITY_RESPONSE. Express dependencies with normal graph edges; do not create a separate safety dependency register.

The planner delegates propagation to GeneralizedImpactAnalyzer, then adds type-specific work, propagation paths, reason edges, stale approvals, unresolved subjects, and cycle findings. Every task starts incomplete. Close it and restore approval through project MOC/document control.

Method 3h — Independent safety verification benchmarks

Use SafetyVerificationBenchmarkSuite to qualify the versioned SIF PFDavg, LOPA residual-frequency, and dynamic-response methods against externally supplied values. Declare the source class, controlled reference, dataset revision, tolerances, and independent-review record. A REGRESSION_BASELINE is useful but deliberately cannot qualify as independent evidence.

Do not call an expected value independent merely because it was entered by a different user. Verify the calculation or published/vendor/CAE source, assumptions, units, method version, and review record outside the code. A passing suite qualifies the controlled implementation/case set, not the project design or SIL target. See docs/process/safety/safety-change-revalidation-and-benchmarks.md.

Method 4 — Bow-Tie Analysis

Use BowTieModel

• BowTieAnalyzer:

import neqsim.process.safety.risk.bowtie.BowTieModel;
import neqsim.process.safety.risk.bowtie.BowTieModel.Threat;
import neqsim.process.safety.risk.bowtie.BowTieAnalyzer;

BowTieModel bt = new BowTieModel("Loss of containment — V-100 gas phase");
bt.addThreat(new Threat("Overpressure", 0.1));
bt.addThreat(new Threat("Corrosion-induced rupture", 0.01));
// preventive barriers reduce threat → top-event frequency
// mitigative barriers reduce consequence severity

BowTieAnalyzer analyzer = new BowTieAnalyzer(bt);
double topEventFreq = analyzer.calculateTopEventFrequency();

Export to SVG with BowTieSvgExporter for the report.

Method 5 — 5×5 Risk Matrix

Use RiskMatrix to score and rank scenarios per ISO 31000 / NORSOK Z-013. Frequencies × Consequence categories → ALARP / intolerable / broadly acceptable bands.

Method 6 — API RP 14C SAFE Chart (offshore device coverage)

Auto-enumerate process equipment and check that each has its API RP 14C–required protective devices (PSH/PSL/LSH/LSL/PSV …) with Api14cSafeChartBuilder:

import java.util.EnumSet;
import neqsim.process.safety.api14c.Api14cSafeChartBuilder;
import neqsim.process.safety.api14c.Api14cDeviceType;

// declarePresent(...) lists the devices actually installed, then build(process)
Api14cSafeChartBuilder chart = new Api14cSafeChartBuilder()
    .declarePresent("HP separator",
        EnumSet.of(Api14cDeviceType.PSH, Api14cDeviceType.PSV))
    .build(process);

boolean complete = chart.isComplete();   // false → missing devices
chart.getGaps();                         // equipment with missing required devices
String md = chart.toMarkdown();          // SAFE chart table
String json = chart.toJson();

buildAssumingComplete(process) enumerates equipment and assumes full coverage (useful for generating the SAFE chart skeleton). Equipment categories come from Api14cEquipmentCategory (e.g. PRESSURE_VESSEL). Verified by Api14cSafeChartBuilderTest.

Method 7 — NORSOK P-002 Process Design Compliance

Screen flare/blowdown/vent hydraulics and drainage against NORSOK P-002 limits with NorsokP002ComplianceChecker (fluent, aggregates all findings):

import neqsim.process.safety.compliance.NorsokP002ComplianceChecker;

NorsokP002ComplianceChecker c = new NorsokP002ComplianceChecker()
    .checkFlareLineMach("Header", 0.5)             // ≤ 0.7 Mach
    .checkBlowdownRhoV2("BDV-1", 150000.0)         // ρv² limit [Pa]
    .checkVentGasVelocity("Vent", 45.0)
    .checkLiquidCarryOver("V-100", 1.0e-4)
    .checkErosionalVelocity("Line-200", 80000.0)
    .recordDepressurisationValve("BDV-2", true, "Sized for fire case")
    .recordDrainSlope("CD-1", true, "1:100 slope OK");

boolean compliant = c.isCompliant();
int failures = c.countNonCompliant();
String json = c.toJson();      // findings tagged e.g. "FLARE_LINE_MACH_07"

Verified by NorsokP002ComplianceCheckerTest.

Method 8 — STS-0131 Technical Safety Gate

Aggregate the project safety acceptance checks (PSV margin, MDMT, SIL, custom) into a single pass/fail gate with Sts0131Gate:

import neqsim.process.safety.compliance.Sts0131Gate;
import neqsim.process.safety.risk.sis.nog070.Nog070SifType;
import neqsim.process.safety.risk.sis.nog070.Nog070SilDetermination;

Sts0131Gate gate = new Sts0131Gate();
gate.addPsvSizingMargin(1.0, 1.15, 0.10);   // required, available, minMargin
gate.addMdmt(-20.0, -29.0);                 // operating MDMT vs design min
gate.addSil(Nog070SilDetermination.evaluate(Nog070SifType.PSD_PROCESS_SEGMENT, 5.0e-3));
gate.addCustom("Fire case", true, "Heat input within API 521 envelope");

boolean acceptable = gate.isAcceptable();
int failures = gate.countFailures();
String json = gate.toJson();

Verified by Sts0131GateTest.

Method 9 — Overpressure-Protection Study (TR3001 / API 521)

Use neqsim.process.safety.overpressure for a structured overpressure study on a protected item: each cause calculator is fluent and returns an immutable ReliefScenario; the engine picks the maximum-rate credible scenario, sizes the PSV (vapour / liquid / two-phase), and checks acceptance against the ASME VIII Div 1 accumulation limits (1.10 single non-fire, 1.16 multiple, 1.21 fire).

import neqsim.process.safety.overpressure.*;

// 1. Cause scenarios (fluent → ReliefScenario)
ReliefScenario blocked = new BlockedOutletRelief().setName("Blocked gas outlet")
    .setInflowRateKgPerHr(36000.0).setReliefPressureBara(50.0)
    .setReliefTemperatureC(20.0).setFluid(gas).calculate();
ReliefScenario fire = new FireCaseRelief().setName("Pool fire")
    .setVesselDiameterM(2.0).setWettedHeightM(3.0)     // or setWettedAreaM2(..)
    .setHasDrainage(true).setHasFireFighting(true)
    .setLatentHeatJPerKg(350000.0).setReliefPressureBara(60.0)
    .setReliefTemperatureC(120.0).setFluid(gas).calculate();

// 2. Engine: governing case + sizing + acceptance
ProtectedItem item = new ProtectedItem("V-100", 100.0)   // tag, MAWP [bara]
    .setReliefSetPressureBara(100.0).setBackPressureBara(1.5);
OverpressureStudyResult result = new OverpressureProtectionStudy(item)
    .addScenario(blocked).addScenario(fire).evaluate();

result.getGoverningScenario().getName();   // worst credible case
result.getRequiredAreaIn2();               // API 526 required orifice area
result.getRecommendedOrifice();            // orifice letter
result.isCapacityAdequate();               // area-based adequacy
result.getAcceptance().getAccumulationFraction();

// 3. TR3001 compliance findings (PASS / FAIL / NEEDS_REVIEW)
List<ComplianceFinding> findings = new TR3001ComplianceChecker().check(result);
boolean compliant = new TR3001ComplianceChecker().isCompliant(findings);

// 4. Disposal-header roll-up (API 521 §5.3)
ReliefDisposalResult disposal = new ReliefDisposalNetwork("Fire zone 1")
    .addRelief(resultA, true).addRelief(resultB, true).calculate();
disposal.getTotalSimultaneousKgPerS();
disposal.getPeakSingleKgPerS();
disposal.getGoverningContributor();

• Cause calculators: BlockedOutletRelief, CheckValveLeakRelief, ControlValveFailureRelief, TubeRuptureRelief, FireCaseRelief.
• Mark double-jeopardy cases non-credible with .credible(false) to exclude them from governing-case selection.
• TR3001ComplianceChecker emits six findings: credible scenarios (SR-26500), governing case (SR-26503), capacity (SR-26506), acceptance (SR-26510), fire basis (SR-26504), and dynamic determination (SR-26565); isCompliant is false if any finding is FAIL.
• Set ReliefScenario phase to LIQUID (densityKgPerM3/viscosityPaS) or TWO_PHASE (gasMassFraction, gasDensityKgPerM3, liquidDensityKgPerM3, latentHeatJPerKg, liquidHeatCapacityJPerKgK) to trigger the matching sizing path; missing two-phase inputs are reported as warnings, not failures.
• Adequacy is judged by area comparison (selectedAreaIn2 ≥ requiredAreaIn2), not by re-plugging the selected area into the nozzle equation — API 520 empirical sizing and the nozzle capacity formula are not inverses.
• Hand the disposal load off to neqsim-relief-flare-network for flare-tip and header hydraulics. Verified by OverpressureProtectionStudyTest + OverpressureExtensionsTest.

Common Mistakes

Validation Checklist

• Each IPL satisfies CCPS independence/specificity/auditability
• No common-cause between adjacent IPLs (sensor, valve, logic solver)
• BPCS PFD ≥ 0.1; operator-action PFD ≥ 0.1
• Target frequency cites a corporate or regulatory criterion
• SIL claimed ≤ SIL achieved by PFD_avg
• Spurious-trip rate documented (production impact)
• Results saved to results.json with safety_analysis section + JSON from LOPAResult.toJson() / SILVerificationResult.toJson()

Verification Tests

./mvnw test -Dtest=Nog070SilCatalogueTest,Sts0131GateTest,Api14cSafeChartBuilderTest,NorsokP002ComplianceCheckerTest,EsdResponseTimeSimulatorTest,OverpressureProtectionStudyTest,OverpressureExtensionsTest

Related Skills

• neqsim-relief-flare-network — when LOPA shows PSV is the IPL of last resort
• neqsim-trapped-liquid-fire-rupture — blocked-in liquid fire rupture, PFP demand, and source-term handoff
• neqsim-self-heating-ignition — spontaneous ignition of combustible liquid absorbed into porous insulation (lagging fires); use for any fire with no identified ignition source
• neqsim-dynamic-simulation — depressurization & blowdown
• neqsim-standards-lookup — IEC 61508/61511, NORSOK Z-013, API 754
