strategy-generate

Workflow

1. Requirements parsing: parse user intent, extract instrument codes, time range, and strategy logic, then write config.json
2. Strategy design: think through the 5 questions of data / signal / position sizing / backtest / validation
3. Strategy coding: write code/signal_engine.py (following the SignalEngine contract)
4. Syntax check: bash("python -c \"import ast; ast.parse(open('code/signal_engine.py').read()); print('OK')\"")
5. Run backtest: call the backtest tool (built into the engine; no need to write run_backtest.py)
6. Evaluate results: read artifacts/metrics.csv and judge by the review criteria
7. Iterative fixing: if results are poor, modify with edit_file → run backtest → re-evaluate

You only need to write signal_engine.py and config.json. The backtest tool automatically handles data loading and backtest execution.

Requirements Parsing

Extract the following from the user's description:

• Instrument codes: process them according to the normalization rules below
• Time range: if the user does not specify dates, default to 10 years back from today (for example, if today is 2026-03-18, then start_date=2016-03-18, end_date=2026-03-18)
• Strategy logic: entry / exit conditions and indicator parameters

If critical information is missing, you must ask the user instead of guessing:

• Instrument not specified → ask which instrument they want to backtest (offer several popular suggestions)
• Strategy description is vague (for example, "help me build a strategy") → provide 2-3 strategy directions for the user to choose from
• Mixed markets but not clearly specified → confirm the data source

Write config.json first, then write code. config.json must be placed in the root of run_dir.

Strategy Design

Before writing code, think through these 5 questions:

1. Data requirements: what fields are needed (basic OHLCV only, daily valuation fields such as pe/pb/roe, or statement fields such as income_total_revenue / fina_indicator_roe?), data frequency (daily), and market (which determines the data source)
2. Signal logic: what are the entry conditions? What are the exit conditions? Direction (long / short / long-short)? Are there filters (volume, trend confirmation, and so on)?
3. Position management: equal-weight allocation or scaling in/out? Risk control (stop-loss, maximum position)? In portfolio strategies, once top N names are selected, each weight = 1/N
4. Backtest parameters: time range, initial capital (default 1,000,000), commission (default 0.1%)
5. Validation checklist: signal consistency (no NaN signals), position check (normalized to prevent leverage), and completeness of generated artifacts

There is no need to output a JSON design document. Express these design decisions directly in code.

SignalEngine Contract

class SignalEngine:
    def generate(self, data_map: Dict[str, pd.DataFrame]) -> Dict[str, pd.Series]:
        """
        Args:
            data_map: code -> DataFrame (columns: open, high, low, close, volume, DatetimeIndex)
                     If config.extra_fields is specified, pe, pb, roe, and similar daily_basic columns will also be present.
                     If config.fundamental_fields is specified, PIT-safe statement columns such as
                     income_total_revenue, income_n_income, and fina_indicator_roe will also be present.
        Returns:
            code -> signal Series, value range [-1.0, 1.0]
            1.0 = fully long, 0.5 = half position, 0.0 = flat, -1.0 = fully short
            Portfolio strategy: selected stocks split weights equally (for example top 10 -> each 0.1)
            Legacy integer signals {-1, 0, 1} remain compatible (treated as -100% / 0% / 100%)
        """

Hard constraints:

• The signal Series index must align exactly with the input DataFrame index
• Include all required imports (numpy, pandas, and so on)
• Do not hardcode dates or stock codes (read them from config.json)
• Do not include an if __name__ == "__main__" block
• Pure pandas / numpy implementation, with no external signal libraries
• Output plain Python code, not Markdown fences

Quality Checklist

Self-check after writing signal_engine.py:

• All imports are included (numpy, pandas, typing, and so on)
• No undefined variables
• Signal logic is consistent with the strategy description
• Boundary handling: for empty data or insufficient history before the lookback window, use fillna(0) or skip
• Portfolio strategy: once N stocks are selected, each weight = 1/N (for example top 10 → each 0.1), unselected names = 0
• Signal values stay within [-1.0, 1.0]

Instrument Code Normalization

• 6-digit China A-share codes → automatically append suffix: codes starting with 600/601/603 → .SH, all others → .SZ
• US stocks: uppercase letters + .US, such as AAPL.US (yfinance converts automatically)
• Hong Kong stocks: digits + .HK, such as 700.HK (yfinance converts automatically)
• Canadian stocks: Yahoo ticker + .TO for TSX or .V for TSXV, such as TD.TO or PNG.V
• Cryptocurrencies: BTC-USDT format (OKX spot pairs, must use the hyphen -, not slash /)
  • The user may write BTC/USDT, but config.json must use "BTC-USDT"

Cryptocurrency Notes

• Code format: must be XXX-USDT (uppercase + hyphen), such as BTC-USDT and ETH-USDT
• source: must be set to "okx"
• extra_fields: must be null (OKX does not support fundamentals)
• Data format: DataLoader has already normalized the output to match China A-shares exactly: open, high, low, close, volume + DatetimeIndex
• No special handling needed in strategy code: signal_engine.py should be written the same way as for China A-shares; do not add extra data conversion for OKX

Market Detection and Data Sources

extra_fields selection logic: only China A-shares (tushare) support daily valuation fields. If the strategy needs PE/PB/ROE and similar daily_basic fields, specify them in config.json.extra_fields and DataLoader will retrieve them automatically. Hong Kong, US, Canadian stocks, and crypto do not support extra_fields.

fundamental_fields selection logic: use this for China A-share financial statement pre-filters. The runner queries income, balancesheet, cashflow, and/or fina_indicator through the Tushare fundamental provider, then merges rows into daily bars only after their announcement/disclosure date. Output columns are prefixed by table name, for example income_total_revenue, income_n_income, balancesheet_total_hldr_eqy_exc_min_int, and fina_indicator_roe.

config.json Format

{
  "source": "auto",
  "codes": ["000001.SZ"],
  "start_date": "2016-03-18",
  "end_date": "2026-03-18",
  "interval": "1D",
  "initial_cash": 1000000,
  "commission": 0.001,
  "extra_fields": null,
  "fundamental_fields": null,
  "optimizer": null,
  "optimizer_params": {},
  "engine": "daily",
  "position_adjustment": "rebalance",
  "rebalance_tolerance": 0.05,
  "validation": null
}

• source: "auto" (recommended, auto-select by code format) / "tushare" / "yfinance" / "okx" / "akshare" / "ccxt"
  • "auto" supports mixed instruments. For example, ["000001.SZ", "BTC-USDT"] will be automatically routed to tushare and okx
  • Futures codes (e.g. "IF2406.CFFEX", "ESZ4") and forex pairs (e.g. "EUR/USD") are also auto-routed
• interval: candlestick interval, default "1D". Supported values: "1m" / "5m" / "15m" / "30m" / "1H" / "4H" / "1D"
  • The annualization factor for minute backtests is inferred automatically from source (252 trading days for China A-shares, 365 calendar days for crypto)
  • Minute backtests can be very data-heavy. Recommended limits are no more than 30 days for 1m, or 1 year for 1H
• extra_fields: China A-shares can use values such as ["pe", "pb", "roe"]; other markets should use null
• fundamental_fields: optional China A-share statement fields, such as {"income": ["total_revenue", "n_income"], "fina_indicator": ["roe"]}; use null unless the strategy needs financial statement pre-filtering
• optimizer: optional, one of "equal_volatility" / "risk_parity" / "mean_variance" / "max_diversification" / "turnover_aware" / null (equal-weight by default)
• optimizer_params: optimizer parameters, such as {"lookback": 60}. mean_variance additionally supports {"risk_free": 0.0}; turnover_aware supports {"risk_aversion": 1.0, "turnover_penalty": 0.5} (L1 penalty on weight changes; tune to data frequency)
• engine: backtest engine, default "daily". For options strategies, set "options" (requires OptionsSignalEngine)
• position_adjustment: always state this explicitly — the two modes produce different books from the same signals, and neither is right for every strategy.
  • "rebalance" executes every target change with market fills and weighted-average entry accounting. It also re-sizes whenever the held weight has drifted from the target, and a strategy restates its target on every bar, so a constant target means a fill on every bar: measured on a 40-bar rising series, a constant 20% target produced 40 fills instead of 1, with the fees, slippage and transaction taxes that follow. A strategy that rebalances on its own schedule (e.g. rebalance_freq=20) will still trade daily here.
  • "hold" keeps a same-direction position until it exits or reverses, so the weight drifts with price and a requested resize is not executed. Dropped requests are counted in the report as dropped_target_adjustment_count, with the first twenty listed, so a rebalance count that does not match the trade log is explained rather than silent.
  • Rule of thumb: "rebalance" when the target weight itself carries the strategy (optimizers, risk budgets, continuous scaling); "hold" when entries and exits carry it and the weight in between is incidental.
• rebalance_tolerance: drift band around the target, as a fraction of it, used only under "rebalance". A resize executes once the held weight has moved further than this from its target; a changed target breaches any sane band on its own, so target changes always execute. Default 0.0 means no band, and then the resize test is decided by the slippage width alone — measured on a constant 20% target over 60 bars, 0.0 produced 60 fills, 0.02 produced 12, and 0.05 produced 5 while the weight never left 0.21. State it for any strategy with its own rebalance cadence, otherwise a rebalance_freq=20 strategy still trades every bar. 0.05 is a reasonable starting point, not a recommendation with evidence behind it — it is your modelling choice and the report records the value the run used.
• initial_cash: default 1,000,000
• commission: default 0.1%
• validation: optional statistical validation after backtest completes. Omit to skip. Example:

  "validation": {
    "monte_carlo": {"n_simulations": 1000},
    "bootstrap": {"n_bootstrap": 1000, "confidence": 0.95},
    "walk_forward": {"n_windows": 5}
  }


  • monte_carlo: permutation test — shuffles trade order to compute p-value (is Sharpe significantly better than random?)
  • bootstrap: resamples daily returns to compute Sharpe 95% confidence interval
  • walk_forward: splits equity curve into N windows, checks performance consistency
  • Each key is optional — include only the validations you want
  • Can also run standalone on past results: python -m backtest.validation <run_dir>

Review Criteria

Hard Gates (any failure → passed=false)

1. artifacts/metrics.csv exists and is non-empty
2. artifacts/equity.csv exists and is non-empty
3. exit_code == 0 (backtest exits normally)
4. The equity column in equity.csv contains no NaN values
5. trade_count > 0 (zero trades = signal bug)

Scoring Rules

• Successful backtest + complete artifacts + at least 1 trade → score ≥ 60 → passed
• Poor return / low Sharpe alone should not push the score below 60; they are optimization suggestions only
• score ≥ 60 = passed=true

Bug Categories (reduce the score)

1. Zero trades (trade_count=0): signal-logic bug, conditions may be too strict
2. Late first trade (first trade > 2 years after backtest start): data-filtering bug or overly long lookback window
3. Capital utilization < 50%: position-management bug, portfolio is flat most of the time
4. Open position at the end (positions still open when backtest ends): exit-signal timing bug

action_items Format

If improvements are needed after evaluation, write action_items:

• Format: "Change X from A to B" or "Add X logic in signal_engine.py"
• Must be specific down to parameter values, file names, and function names
• At least 2 items
• Examples:
  • "Change short MA from 5 to 10 days to reduce whipsaw signals"
  • "Add stop-loss: force close when loss exceeds 5%"
  • "Add volume filter in signal_engine.py: only trigger buy on high volume"

Cross-Market Strategies

When the user requests a backtest with codes from different markets (e.g. ["000001.SZ", "BTC-USDT"]):

• Set source: "auto" in config.json
• The CompositeEngine handles calendar alignment, shared capital, and per-market rules automatically
• Use volatility-adjusted weights so high-vol assets (crypto) don't dominate the risk budget
• See the cross-market-strategy skill for per-market parameters, vol-adjustment, and example code

Supporting Files

• examples.md — example call sequence
